10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel
10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel
10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel
10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel
10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel
10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel
10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel
10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel
10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel

10 inch 10x6-5.5 wide tyre hubmotor 600W and 4000W option for diy one wheel

$149.00

This is most widely used hubmotor for diy onewheeled electric skateboard

Technichal Data:

  • Voltage: 60V
  • Rated Power: 600W
  • Size: 10inch
  • Tyre width: 150mm
  • Axel out length:31mm
  • Shaft diameter: 14mm
  • Poles: 30

Test Data in VESC Tool

ERPM is 4519 , under 24.3v inputs with no loading , the calculated KV is 12.39

    600w fat hubmotor for diy balanced board



    4000W motor spec:

    Size:   Stator : 105*95mm, Magnet: 95mm H

    Max voltage： 72V

    Rated power: 4000W

    Max current :  100-120A

    Speed : 70km/h

    Torque: 50Nm

    Recommend to use this UBOX to work with it .

     Test data for 4000W motor in VESC tool

     ERPM is 12744 , under 41v inputs with no loading , the calculated KV is 20.72
