1. the motor color is black as default shipping.
2. Support 33x2 winding,but no hall
Motor Spec:
| Model Version |
Half-detachable Rim |
Full detachable Rim |
| Voltage |
60V-96V |
Same |
| Rated Power |
4000W |
3500W |
| Magnet Length |
65H |
60H |
| Stator Size |
110mm |
105mm |
| Cable Size |
4mm²(12AWG) /or Teflon |
Same |
| RPM |
2450RPM |
2500RPM |
| Max Torque |
65Nm |
55Nm |
| Wheel Size |
80/65-6 10x2.75 with tube |
Same |
| Motor Type |
Half side split |
two side split |
| Speed |
100-160km/h |
Same |
| Open size |
125-138mm range |
Same |
| KV |
30/22/18 |
35/26/23 |
| Cable length |
115cm |
Same |
| Shaft Size |
M14 |
Same |
Recommended motor controller :
Dual Ubox V2 75V 100A*2 motor controller based on VESC
Single ubox alum 85V 150A motor controller based on VESC
