1. the motor color is black as default shipping.
2. 65H motor don't have 33x2 winding with hall sensor. 60H has 33x2 winding with hall sensor.
3. All upgrade to Teflon cable with protective sleeve. Teflon cable can afford higher temp(max 180degree)
4. Upgrade version :
-
Upgrade the magnets from N38SH to N40SH.
-
Upgrade the winding copper cables to 180degree anti-high temp cables.
-
Power can increase 500-800W, torque increase 10Nm
Motor Spec:
| Model Version |
Half-detachable Rim |
Half detachable Rim |
| Voltage |
60V-96V |
Same |
| Rated Power |
4000W |
3500W |
| Magnet Length |
65H |
60H |
| Stator Size |
110mm |
110mm |
| Cable Size |
4mm²(12AWG) /or Teflon |
Same |
| RPM |
2450RPM |
2500RPM |
| Max Torque |
65Nm |
55Nm |
| Wheel Size |
80/65-6 10x2.75 with tube |
Same |
| Motor Type |
Half side split |
Same |
| Speed |
100-160km/h |
Same |
| Open size |
125-138mm range |
Same |
| KV (tolerance +/-1) |
30/22/18 |
33/24/21/46 |
| Cable length |
115cm |
Same |
| Shaft Size |
M14 |
Same |
Recommended motor controller :
Dual Ubox V2 75V 100A*2 motor controller based on VESC
Single ubox alum 85V 150A motor controller based on VESC
