High speed motor for scooter racing!
Motor spec
| Rated Voltage |
72V-96V |
Torque |
<=80 Nm |
| Rated Power |
4000W-6000W |
Speed range
|
100-150km/h |
| Rated RPM(No loading) |
2900-3000 RPM |
Wheel size fit for |
90/65-6.5
110/55-6.5
|
| Motor type |
Split motor |
Cable size |
10mm²(7AWG) |
| Magnet size |
80mm |
Wheel type |
Tubless |
| Drop out size |
170mm |
Stator Size |
110mm |
| Shaft Size |
M14 M10flat |
KV(80H) |
(Torque/Standard/Speed)17 /25/ 38 |
Rim Size Options: Choose Rim here
| Rim Size |
Fit for Wheel Size |
| 110mm |
13*5-6.5 |
| 100mm |
12*4.5-6.5 |
| 90mm |
90/65-5.5 |
| 70mm |
90/55-6.5 |
Motor Controller recommendation:
Depending on your battery pack spec, here is two option:
Dual ubox v2 75V 100A*2 motor controller based on VESC
Single ubox alum 85V250A controller based on VESC
